Lin log axis (xfig example)

require("isisscripts");

%%%%%%%%%%%%%%%%%%%%% define function for axis transformation:
private define mylinlog_wcs_func (val, opt)
{
  variable brk = opt.brk;
  variable scl = opt.scl;
  variable is_array = typeof (val)==Array_Type;
  variable x = [@val];
  variable i1 =[where(x > brk)];
  variable i2 =[where(-brk <= x <= brk)];
  variable i3 = [where(x < -brk)];
  x[i1] =  log(x[i1]/brk)+brk*scl;
  x[i2] =  x[i2]*scl ;
  x[i3] = -log(-x[i3]/brk)-brk*scl;
  return is_array ? x : x[0] ;
}

%%%%%%%%%%%%%%%%%%%%% define inverse function for axis transformation:
private define mylinlog_wcs_invfunc (val, opt)
{
  variable brk = opt.brk;
  variable scl = opt.scl;
  variable is_array = typeof (val)==Array_Type;
  variable x = [@val];
  variable i1 =[where(x > brk)];
  variable i2 =[where(-brk <= x <= brk)];
  variable i3 = [where(x < -brk)];
  x[i1] =  exp(x[i1]-brk*scl)*brk;
  x[i2] =  x[i2]/scl ;
  x[i3] = -exp(-x[i3]-brk*scl)*brk;
  return is_array ? x : x[0] ;
}

%% "opt" is ONE optional argument (for more information use, e.g., a non-skalar argument)
%% check of array or not is only required due to the different cases. other functions
%% can simply use: return f(val);

xfig_plot_add_transform ("mylinlog", &mylinlog_wcs_func, &mylinlog_wcs_invfunc, struct{brk=1,scl=1} );

%%%%%%%%%%%% generate some data:
variable xlim = 50;
variable x = [-(xlim^[1:0:#100]) , [-1:1:#50] , xlim^[0:1:#100] ];
variable y = exp(-1/(0.2+x^2))/(x^2+0.1);

variable major = [0,[1,10,50],-dup];
variable minor = [[1:9]*0.1,-dup,[2:9], -dup, 10*[2:4], -dup];
%%%%%%%%%%%% plot data:
variable p = xfig_plot_new (14,10);
p.world (-(xlim^1.1), -dup, min_max(y); ylog, pady=0.05);
p.xaxis(;wcs="mylinlog", minor = minor, major=major);
p.x2axis(; ticlabels = 0);
p.plot(x,y);
p.render("lin_log_axis.pdf");
